Thông tin chi tiết sản phẩm:
|
| Tên sản phẩm: | công cụ ổ cứng | Các ngành áp dụng: | Công trình xây dựng, Năng lượng và khai thác mỏ, Xây dựng cơ sở hạ tầng |
|---|---|---|---|
| Kiểu: | mũi doa | Loại máy: | Dụng cụ khoan |
| Vật liệu: | thép | Loại xử lý: | vật đúc |
| Đường kính bên ngoài: | 200mm-1000mm | Ứng dụng: | khoan định hướng ngang |
| Cách sử dụng: | Đối với giàn khoan định hướng ngang | Dịch vụ OEM: | Chấp nhận |
| Làm nổi bật: | 270KG Drill Head,127MM Drill Head |
||
Casting Pilot Guide Bit For Horizontal Directional Drilling
Product Description
Sonde Housings with a variety of thread configurations. Our Side-Load Housings are manufactured from American-Made 4140 Alloy. Our Heat Treatment Process and optional Hard Facing give you the wearability you can count on. They are offered for Duck Bill or Carbide Bits.
| Type | Type of threads (K) | External diameter (B) | Carbon storehouse size (L) | Weight (KG) |
| 73 Drill Head Series | 50 Drill pipe threads | Φ73 | 380 | 17 |
| 83 Drill Head Series | 60 Drill pipe threads | Φ83 | 380/480 | 23/27 |
| 83 Drill Head Series | 73 Drill pipe threads | Φ83 | 380/480 | 25/29 |
| 88 Drill Head Series | 76 Drill pipe threads | Φ88 | 380/480 | 26/30 |
| 93 Drill Head Series | 83 Drill pipe threads | Φ93 | 380/480 | 32/36 |
| 108 Drill Head Series | 89 Drill pipe threads | Φ108 | 380/480 | 44/48 |
| 127 Drill Head Series | 102 Drill pipe threads | Φ127 | 380/480 | 73/78 |
| 168 Long Drill Head Series | 127 Drill pipe threads | Φ168 | 480 | 150 |
| 194 Long Drill Head Series | 140 Drill pipe threads | Φ194 | 480 | 270 |
Features
Formation:suitable for sand and medium to very hard soil
Structure:steel casing,welded
Connection with drill rod:octagonal connection direct connection with drill rod
Connection with laid pipe:within or without swivel
FAQ
Q: What is your delivery time?
A: It usually takes 20 days to produce. Within 3 days (if there is stock).
Q: How to control the quality?
A: Before shipping, we should check and test each drill rod.
Q: Do you agree to order samples?
A: Yes, we welcome your sample order to test our quality.
Q: Has your drill pipe been heat treated?
A: Yes, our heat treatment of drill pipe and casing.
Q: Does your drill pipe have anti-rust function?
A: Yes, each drill pipe and casing will be anti-rust with paint or anti-corrosion oil before transportation. If you need galvanized pipe, please contact us.
